Manuals, standards & metering
We take safety seriously - and we share this commitment with our contractors, installers and anybody who needs to work near our network. We want to make sure you, your workmates and the community remain safe and the power remains on.
Always follow the manuals and industry standards relevant to your project and work environment to make sure your work is carried out safely and in line with the relevant laws and regulations.
Tab content 1
| Technical Rules | ||
|---|---|---|
|
|
HPC-9DJ-01-0001-2012 Horizon Power Technical Rules (Pilbara Grid and Non Interconnected Systems) [2.29 MB] |
|
|
|
Technical Rules Derogation for Dampier 33kV (April 2017) [0.26 MB] |
|
|
|
PowerFactory Modelling Guideline [2.72 MB] |
|
|
|
Guidance note - Application of the Harmonised Technical Rules and Horizon Power Technical Rules [0.09 MB] |
|
Horizon Power is committed to meeting all legal obligations in relation to legislative, regulatory and environmental requirements. Our Safety, Health & Wellbeing Policy is available below with all other Safety and Health Management System documentation available through the Contractor and Tender portals.
| Safety | ||
|---|---|---|
|
|
Safety, Health & Wellbeing Policy [0.14 MB] |
|
| Forms and exemptions | ||
|---|---|---|
|
|
46-2017-1837 - Horizon Power (Covering Letter + Exemption) [0.31 MB] |
|
|
|
LV SCT Form - Network Analyser [0.41 MB] |
|
|
|
Regional Power Corporation (Horizon Power) - TFB Exemption 22C - 30 June 2018 [0.94 MB] |
|
Download the Switchgear Instruction Manual - SIM
| Switching operators manual, process and rules | ||
|---|---|---|
|
|
Switching Authorisation Form [0.25 MB] |
|
|
|
Switching Operators Manual - Distribution [11.90 MB] |
|
|
|
Switching Operators Manual - Transmission [11.90 MB] |
|
|
|
Switching Process and Rules [1.07 MB] |
|
| DCS Part 1-9 | ||
|---|---|---|
|
|
DCS Part 2 - (R) Reference [4.24 MB] |
|
|
|
DCS Part 4 - (H) HV Overhead [5.90 MB] |
|
|
|
DCS Part 5 - (U) LV Underground [1.66 MB] |
|
|
|
DCS Part 6 - (L) LV Overhead [0.34 MB] |
|
|
|
DCS Part 7 - (A) LVABC [0.36 MB] |
|
|
|
DCS Part 8 - (S) Streetlights [0.43 MB] |
|
|
|
DCS Part 9 - (M) Miscellaneous [ MB] |
|
| DCS Part 10 Distribution Substation | ||
|---|---|---|
|
|
(G1) Customer Supply Arrangements [0.76 MB] |
|
|
|
(G2) MV Network Arrangements [1.20 MB] |
|
|
|
(G3) Substation Arrangements [6.80 MB] |
|
|
|
(G4) Equipment Installation Guide [3.13 MB] |
|
|
|
(G5) Fire Protection Requirements [0.45 MB] |
|
|
|
(G6) Miscellaneous [3.83 MB] |
|
|
|
(G7) Superseded Equipment (G7 conversion in progress) [0.93 MB] |
|
|
|
(G8) Distribution Automation [0.93 MB] |
|
|
|
(G9) Environmental Protection [0.30 MB] |
|
| DCS Part 11 (X) Maintenance | ||
|---|---|---|
|
|
DCS Part 11 - (X) Maintenance [1.33 MB] |
|
| DCS Part 12 T -Stringing Charts | ||
|---|---|---|
|
|
DCS Part 12 T -Stringing Charts [7.71 MB] |
|
| Distribution Design | ||
|---|---|---|
|
|
HPC-9DJ-01-0002-2015 Distribution Design Rules [ MB] |
|
|
|
WA Service and Installation Requirements WASIR April 2023 [9.80 MB] |
|
| Distribution Design Catalogue | ||
|---|---|---|
|
|
HPC-1DC-07-0001-2014 - Cat - DDC High Voltage Bare (HV) [ MB] |
|
|
|
HPC-1DC-07-0002-2014 - Cat - DDC Poles (PO) [0.68 MB] |
|
|
|
HPC-1DC-07-0003-2014 - Cat - DDC Running Earth and Earthing (RE) [0.74 MB] |
|
|
|
HPC-1DC-07-0004-2014 - Cat - DDC Low Voltage Bare (LV) [0.82 MB] |
|
|
|
HPC-1DC-07-0005-2014 - Cat - DDC Low Voltage ABC (AB) [0.92 MB] |
|
|
|
HPC-1DC-07-0006-2014 - Cat - DDC Stays (ST) [0.83 MB] |
|
|
|
HPC-1DC-07-0007-2014 - Cat - DDC Conductor and Fittings (CN) [ MB] |
|
|
|
HPC-1DC-07-0008-2014 - Cat - DDC Transformers (TX) [ MB] |
|
|
|
HPC-1DC-07-0009-2014 - Cat - DDC Distribution Automation (DA) [0.89 MB] |
|
|
|
HPC-1DC-07-0010-2014 - Cat - DDC High Voltage Underground (HU) [ MB] |
|
|
|
HPC-1DC-07-0011-2014 - Cat - DDC Low Voltage Underground (LU) [ MB] |
|
|
|
HPC-1DC-07-0012-2014 - Cat - DDC Street Lighting (SL) [ MB] |
|
|
|
HPC-1DC-07-0013-2014 - Cat - DDC Decorative Materials (DM) [1.04 MB] |
|
|
|
HPC-1DC-07-0014-2014 - Cat - DDC Network Devices (ND) [0.26 MB] |
|
|
|
HPC-1DC-07-0015-2014 - Cat - DDC Low Voltage Metering (LM) [0.76 MB] |
|
|
|
hpc-1dc-07-0016-2014 - Cat - DDC Unmetered Supply (UM) [1.28 MB] |
|
| Distribution Commissioning Test Sheets | ||
|---|---|---|
|
|
HPC-4DL-07-0001-2014 DCT - CT Metered LV Customer Connections [0.40 MB] |
|
|
|
HPC-4DL-07-0002-2014 DCT - Distribution Substation (Fire Rated) [0.21 MB] |
|
|
|
HPC-4DL-07-0003-2014 DCT - Distribution Substation (Non-Fire Rated) [0.27 MB] |
|
|
|
HPC-4DL-07-0004-2014 DCT - Earth Testing for Distribution Substations [0.12 MB] |
|
|
|
HPC-4DL-07-0005-2014 DCT - HV XLPE Cables [0.26 MB] |
|
|
|
HPC-4DL-07-0006-2014 DCT - HV Cables Repair Faults [0.28 MB] |
|
|
|
HPC-4DL-07-0007-2014 DCT - HV Cust Conn or Reconnection [0.26 MB] |
|
|
|
HPC-4DL-07-0008-2014 DCT - HV Mixed Cables [0.34 MB] |
|
|
|
HPC-4DL-07-0009-2014 DCT - HV Overhead Lines [0.05 MB] |
|
|
|
HPC-4DL-07-0012-2014 DCT - HV RMU Switchgear [0.17 MB] |
|
|
|
HPC-4DL-07-0013-2014 DCT - Load Break Switch [0.16 MB] |
|
|
|
HPC-4DL-07-0014-2014 DCT - LV Aerial Bundled Conductor [0.07 MB] |
|
|
|
HPC-4DL-07-0016-2014 DCT - LV Cables with or without pillars or pits [0.22 MB] |
|
|
|
HPC-4DL-07-0017-2014 DCT - LV Overhead Lines [0.04 MB] |
|
|
|
HPC-4DL-07-0018-2014 DCT - LV Kiosk [0.12 MB] |
|
|
|
HPC-4DL-07-0019-2014 DCT - MPS Dist Trfr [0.16 MB] |
|
|
|
HPC-4DL-07-0021-2014 DCT - Non MPS Dist Trfr [ MB] |
|
|
|
HPC-4DL-07-0023-2014 DCT - Pole Top Switch [0.15 MB] |
|
|
|
HPC-4DL-07-0024-2014 DCT - Three Ph Pole Mounted Trfr [0.17 MB] |
|
|
|
HPC-4DL-07-0025-2014 - DCT - Pole Mounted Cap Bank [ MB] |
|
|
|
HPC-4DL-07-0026-2014 DCT - Nulec Pole Mounted Recloser [0.14 MB] |
|
|
|
HPC-4DL-07-0027-2014 DCT - Poles and Line Hardware WITHDRAWN [0.65 MB] |
|
|
|
HPC-4DL-07-0028-2014 DCT - Private Parallel Generators [0.27 MB] |
|
|
|
HPC-4DL-07-0029-2014 DCT - Single Ph Pad-Pole Mounted Trfr [0.17 MB] |
|
|
|
HPC-4DL-07-0031-2014 DCT - Steel Pole Streetlights [0.10 MB] |
|
|
|
HPC-4DL-07-0032-2014 DCT - Voltage Regulator (Closed Delta) [ MB] |
|
|
|
HPC-4DL-07-0034-2014 DCT - Network Access Points (AP's) & Relays [0.18 MB] |
|
|
|
HPC-4DL-07-0035-2016 DCT - LV Cables Repair Faults w-out disconnect [0.26 MB] |
|
|
|
HPC-4DL-07-0036-2017 DCT - Streetlight component replacement [0.16 MB] |
|
|
|
HPC-4DL-07-0037-2017 DCT - Earth Testing of Altered Systems [0.07 MB] |
|
|
|
HPC-4DL-07-0038-2017 DCT - Earth Testing of Distribution Poles [0.15 MB] |
|
|
|
HPC-4DL-07-0039-2022_DCT - Power Pole Streetlight [0.34 MB] |
|
|
|
HPC-4DL-07-0040-2023 DCT - NOJA Pole Mounted Recloser [0.15 MB] |
|
|
|
HPC-4DL-07-0041-2023 DCT - Three Ph Pole Mounted Reactor.pdf [0.16 MB] |
|
|
|
HPC-4DL-07-0043-2024- DCT – Isolation Pole Mounted Transformer [0.14 MB] |
|
|
|
HPC-4DL-07-0044-2024 DCT - Network Access Points (Streetlight).pdf [0.20 MB] |
|
| Distribution Data Sheets | ||
|---|---|---|
|
|
Data Sheet Templates 2025.xlsx [ MB] |
|
| Interim Instructions | ||
|---|---|---|
|
|
AMS 2024/001 - TE Connectivity - Preformed Dead-End Performance Issue [1.00 MB] |
|
|
|
AMS 2023/001 – Post Insulator Clamp | |
|
|
AMS 2023/002 – RMU and SF6 disposal - Hazard | |
|
|
AMS 2020/001 - Application of LV spreaders [0.21 MB] |
|
|
|
AMS 2020/002 - Single Phase Spur Fusing [0.16 MB] |
|
|
|
AMS 2014/001 – Protection of Steel Standard Poles incorporating Street Lights [2.37 MB] |
|
|
|
AW 2012/009 - Installation & Replacement of Service Cables [0.08 MB] |
|
Tab content 1
| Guidelines | ||
|---|---|---|
|
|
Electricity Network Safety Management System Guide [8.71 MB] |
|
|
|
HPC-2DC-17-0002-2022_Gdl_Safety_in_Design.pdf [1.48 MB] |
|
|
|
HPC-2DJ-12-0001-2017 – Design Submission Checklist [0.07 MB] |
|
|
|
HPC-2NJ-01-0001-2015 - Gdl - Operations Requirements to add Assets [0.70 MB] |
|
|
|
Injury Classification Definitions [0.03 MB] |
|
|
|
OSH 3.6-1-32 Contractor Safety and Health Guidelines [0.39 MB] |
|
|
|
Sulphur Hexafluoride Management [0.40 MB] |
|
| Manuals | ||
|---|---|---|
|
|
HPC-5DA-07-0012-2015 - Man - Underground Distribution Scheme Manual [1.50 MB] |
|
| Policies | ||
|---|---|---|
|
|
Distribution Subdivision Policy - HPC-11AH-07-0002-2015 [0.44 MB] |
|
|
|
Unmetered Supply Policy HPC-11DR-16-0001-2015 [0.45 MB] |
|
|
|
Third Party Attachments to Horizon Power Assets Policy - HPC-11NH-18-0001-2011 [ MB] |
|
|
|
Distribution Pole to Pillar Guideline - HPC-2AH-07-0001-2014 [0.66 MB] |
|
| Procedures | ||
|---|---|---|
|
|
HPC-2DK-05-0001-2017 - Procedure for contractors - SPD replacement [0.83 MB] |
|
|
|
HPC-7DC-08-0001-2013_-_Pcd_-_Substation_Lightning_Protection_Design.pdf [1.32 MB] |
|
| Standards | ||
|---|---|---|
|
|
HPC-9AJ-01-0001-2014_-_Std_-_Coating_and_Colour_Coding.pdf [0.47 MB] |
|
|
|
HPC-8DJ-14-0001-2015 - Std - Street Lighting for Turtle Nesting Areas [0.70 MB] |
|
|
|
HPC-9AF-07-0001-2011 - Std - General Template Labelling Standard for Distribution Equipment [1.74 MB] |
|
|
|
HPC-9CA-01-0001-2012 - Std - Engineering Drawings CAD General Requirements, Practices and Preparation of Drawings [ MB] |
|
|
|
HPC-9CA-01-0002-2012 - Std - Numbering and Titling Specification [0.87 MB] |
|
|
|
HPC-9DC-14-0001-2017 - Std - Streetlight Poles [0.43 MB] |
|
|
|
HPC-9DJ-13-0001-2019 – Basic EG Connection Technical Requirements [ MB] |
|
|
|
HPC-9DJ-13-0002-2019 – Low Voltage EG Connection Technical Requirements [ MB] |
|
|
|
HPC-9EJ-01-0001-2013 - Std - Horizon Power Environmental Conditions [3.23 MB] |
|
|
|
HPC-9OJ-13-0001-2012 - Std - Transfer of Customer Load between Embedded Generators and the Distribution Network [0.47 MB] |
|
| Specifications | ||
|---|---|---|
|
|
HPC-8DC-23-0001-2015 - Substation Power Transformer Specification [1.67 MB] |
|
|
|
HPC-8DJ-03-0001-2012 - Medium Voltage Cable Accessories Technical Requirements [1.43 MB] |
|
|
|
HPC-8DJ-03-0002-2016 - Low Voltage Cable Accessories [0.93 MB] |
|
|
|
HPC-8DJ-03-0003-2012 - Low Voltage Power Cables with Rated Voltage Technical Requirements [2.37 MB] |
|
|
|
HPC-8DJ-03-0004-2013 - Medium Voltage Power Cables [0.82 MB] |
|
|
|
HPC-8DJ-03-0005-2012 - Overhead Conductors up to and including 33 kV Technical Requirements [1.47 MB] |
|
|
|
HPC-8DJ-07-0001-2013 - Distribution Transformers Specification [2.96 MB] |
|
|
|
HPC-8DJ-07-0002-2013 - SF6 Ring Main Units (RMU) Specification [0.81 MB] |
|
|
|
HPC-8DJ-07-0003-2014 - Distribution Reclosers Technical Requirements [1.61 MB] |
|
|
|
HPC-8DJ-07-0004-2016 - Insulators Specification [0.82 MB] |
|
|
|
HPC-8DJ-07-0006-2021 - Medium Voltage Surge Arrester [1.19 MB] |
|
|
|
HPC-8DJ-07-0007-2022 - Medium Voltage Transformer [0.68 MB] |
|
|
|
HPC-8DJ-07-0008-2023 - Air Insulated Ring Main Unit Switchgear [ MB] |
|
|
|
HPC-8DJ-07-0009-2023 - SPEC - Public Electricity Network Distribution Assemblies [2.90 MB] |
|
|
|
HPC-8DJ-07-0010-2025 - MV Current Transformer [ MB] |
|
|
|
HPC-8DJ-12-0001-2022 - Standalone Power System (SPS) Specification [3.94 MB] |
|
|
|
HPC-8DJ-12-0003-2019 - Spec– LV Energy Storage System [1.90 MB] |
|
|
|
HPC-8DJ-14-0001-2013 - LED Luminaires and Control Switches for Street Lighting Specification [1.26 MB] |
|
|
|
HPC-8DJ-16-0001-2013 - Revenue Electricity Meters Specification [0.40 MB] |
|
|
|
HPC-8DJ-16-0002-2013 - Metering MV CT-VT Units Technical Requirements [1.97 MB] |
|
|
|
HPC-8DJ-23-0001-2013 - Medium Voltage Switchboard [1.13 MB] |
|
|
|
HPC-8DJ-25-0001-2021 - HV Surge Arrester Specification [1.24 MB] |
|
|
|
HPC-8DJ-25-0002-2022 - HV Capacitor Voltage Transformers [1.53 MB] |
|
|
|
HPC-8DJ-25-0003-2023 - HV Current Transformers Specification [1.47 MB] |
|
|
|
HPC-8DJ-25-0004-2023 - Specification– HV Composite Insulators [0.90 MB] |
|
|
|
HPC-8DJ-25-0005-2023 - Specification– HV Circuit Breakers [1.59 MB] |
|
|
|
HPC-8DJ-25-0006 - 2024 - Spec - HV Disconnector and Earth Switch.pdf [1.70 MB] |
|
|
|
HPC-8DJ-25-0007 - 2025 - Spec - MV Capacitor Banks [ MB] |
|
|
|
HPC-8MJ-07-0001-2016 - Low Voltage Composite Cross-arms Specification [0.78 MB] |
|
|
|
HPC-8MJ-07-0002-2018 - Medium Voltage Composite Cross-arms Specification [0.84 MB] |
|
|
|
HPC-8MJ-18-0001-2016 - Distribution Network Poles [2.31 MB] |
|
|
|
HPC-8MJ-09-0002-2023_-_Spec_-_Precast_Concrete_Items.pdf [1.37 MB] |
|
Tab content 1
Metering requirements
The following links provide the electrical consulting and electrical contracting industries information regarding all requirements for any connection, of all types of installations, to a Horizon Power Network.
Mandatory Link Criteria and Metrology Procedure
Horizon Power has received approval from the Economic Regulation Authority for the mandatory link criteria under Part 6 of the Electricity Metering Code.
The mandatory link criteria deals with the communication links required by metering installations so as to enable meters to be read from remote locations via telecommunication networks.
The following documents explain the Horizon Power's Mandatory Link criteria, Metrology Procedure for Meter Installations and the approval received from the Economic Regulation Authority.
| Useful documents | ||
|---|---|---|
|
|
Communication Rules - Metering services [0.88 MB] |
|
|
|
Mandatory Link Criteria - Metering Services [0.62 MB] |
|
|
|
Meter Reading Schedule 2025/26 | |
|
|
Metrology Procedure - Metering Services [1.57 MB] |
|
|
|
Service Level Agreement - Metering Services [0.77 MB] |
|
Tab content 1
| Useful resources | ||
|---|---|---|
|
|
Horizon Power manuals, standards & guides | |
|
|
Australian Standards | |
|
|
Building and Energy | |
|
|
Code of Practice - Persons working on or near energised electrical installations | |
|
|
Code of Practice - Inspectors (Electricity) | |
|
|
Code of Practice - Utility Providers | |
|
|
Metering information | |
|
|
WA Electrical Requirements (WAER) | |
|
|
WA Service and Installation Requirements WASIR [9.80 MB] |
|
Metering requirements
The following links provide the electrical consulting and electrical contracting industries information regarding all requirements for any connection, of all types of installations, to a Horizon Power Network.
